Assembly fixture for
fire-door frames

This customized assembly fixture was developed for the precise and efficient production of fire door frames with high product variability. It enables reliable and repeatable pre-assembly of frame profiles while maintaining tight tolerances, even for large component dimensions.

A flexible fixture-system enables processing of up to 24 profile variants. Adjustable clamping and positioning elements allow precise adaptation to different door formats. Ergonomically designed work areas support both manual and automated loading operations.

Based on form- and force-locking fixation, the fixture achieves high repeatability with short cycle times. The robust design ensures long-term durability in industrial environments, making it ideal for manufacturers of door, gate, and window systems requiring flexibility, stability, and precision.
